Cat. No.				G8DDT10E
Parameters
Supply Voltage				110 - 240 VAC
Supply Variation				-20% to +10%
Frequency				50/60 Hz
Power Consumption				5W
Digital Input				8
Analog Input				N A
Digital Input Range				(0 - 40 VAC) OFF, (80 - 265 VAC) ON
Analog Input Range				N A
Digital Output	Relay Output			4 NO
	Contact Rating			8A @ 240 VAC / 5A @ 30 VDC (Resistive)
	Electrical Life			105
	Mechanical Life			107
Utilization Category			AC - 15	Rated Voltage (Ue): 120/240 V, Rated Current (Ie): 3.0/1.5 A
			DC - 13	Rated Voltage (Ue): 24/125/250 V, Rated Current (Ie): 2.0/0.22/0.1 A
I/O Extensions (Max.)				3
Power Reserve (For Clock Only)				7 yrs. (at -10oC to 55oC)
Modbus Communication				Yes (RTU) (Slave)
DST				Settable
Lines for Ladder Programming				250
Function Blocks		Timers		16 (ON Delay, Interval, Cyclic ON-OFF, OFF Delay)
		Counters		16 (Up / Down, Retentive selectable)
		Time Switches		16 (Weekly / Daily)
		Compare Counters		16
		Analog Functions		N A
		Soft Text Messages		16 (Priority Driven)
		Auxiliary Relays		64
		Hour Meter		4
Operating Temperature Storage Temperature				-10O C To + 55O C -25O C To + 70O C
Humidity (Non Condensing)				95% (Rh)
Enclosure				Flame Retardant UL 94-V0
Dimension (W x H x D) (in mm)				72 X 90 X 65
Weight (unpacked) Approx.				230 g
Mounting				Base / DIN Rail
Degree of Protection				IP 20 for Terminals, IP 40 for Enclosure
Certification

EMI I EMC
Harmonic Current Emissions	IEC 61000-3-2 ESD
Radiated Susceptibility	IEC 61000-4-3
Electrical Fast Transients	IEC 61000-4-4
Surges	IEC 61000-4-5
Conducted Susceptibility	IEC 61000-4-6 Voltage Dips & Interruptions (AC) IEC 61000-4-11 Voltage Dips & Interruptions (DC) IEC 61000-4-29 Conducted Emission
Radiated Emission	CISPR 14-1
Environmental
Cold Heat	IEC 60068-2-1
Dry Heat	IEC 60068-2-2
Vibration	IEC 60068-2-6
Repetitive Shock	IEC 60068-2-27
Non-Repetitive Shock	IEC 60068-2-27

---

---

---
