Cat. No.	23GDT0
Parameters
Timer Description	True OFF Delay (Power OFF Delay) Timer

Supply Voltage					24 - 240 VAC/DC
Supply Variation					-10 to +20%
Frequency					50/60 Hz
Power Consumption (Max.)					2.5 VA
Energizing Time					1s (Minimum)
Timing Range					0.6s to 600s
Setting Accuracy					± 5% of Full scale
Repeat Accuracy					± 1%
	Relay Output				2 C/O
Output	Contact Rating				5A @ 240 VAC / 28 VDC (Resistive)
	Electrical Life				1x105
	Mechanical Life				1x107
Utilization Category				AC-15	Rated Voltage (Ue): 120/240 V, Rated Current (Ie): 3.0/1.5 A
				DC-13	Rated Voltage (Ue): 24/125/250 V, Rated Current (Ie): 2.0/0.22/0.1 A
Operating Temperature					-15°C to +60°C
Storage Temperature					-20°C to +70°C
Humidity (Non Condensing)					95% (Rh)
LED Indication					Green LEDPower ON, Red LEDRelay ON
Enclosure					Flame Retardant UL94-V0
Dimension (W x H x D) (in mm)					22.5 X 75 X 100.5
Weight (unpacked)					130 g
Mounting					Base / DIN Rail
Certification					RoHS Compliant
Degree of Protection					IP 20 for Terminals, IP 40 for Enclosure

EMI / EMC
Harmonic Current Emissions	IEC 61000-3-2
ESD	IEC 61000-4-2
Radiated Susceptibility	IEC 61000-4-3
Electrical Fast Transients	IEC 61000-4-4
Surges	IEC 61000-4-5
Conducted Susceptibility	IEC 61000-4-6
Voltage Dips & Interruptions (AC)	IEC 61000-4-11
Voltage Dips & Interruptions (DC)	IEC 61000-4-29
Conducted Emission	CISPR 14-1
Radiated Emission	CISPR 14-1
Environmental
Cold Heat	IEC 60068-2-1
Dry Heat	IEC 60068-2-2
Vibration	IEC 60068-2-6
Repetitive Shock	IEC 60068-2-27
Non-Repetitive Shock	IEC 60068-2-27

---

---

---
