• Battery charger with safety relay 10 A 12 VDC
Item Name: Battery charger with safety relay 10 A 12 VDC
SKU 1: BPRB 1012M
SKU 2: 0
Category: BPRB RANGE
Brand: CRE TECHNOLOGY

REFERENCES UNIT BPRB 1012M
OUTPUT CURRENT A 10
OUTPUT VOLTAGE VDC 12_15
DC VOLTAGE ADJUSTABLE . yes
INPUT VOLTAGE RANGE VAC 180~550
INPUT fREQUENCY RANGE Hz 47-63
EffICIENCY (TYPICAL) % 89.5
WORKING TEMPERATURE °C -25 / +70
STORAGE TEMPERATURE °C -40 / +85
WIDTH mm 40
HEIGHT mm 125.2
DEPTH mm 113.5
WEIGHT kg 0.65
fAILURE RELAY . yes
BOOST MODE (ACTIVATED BY EXTERNAL CONTACT)   yes
