Tipo				CO1P
Rated current		(In)		63A
Rated insulation voltage	c.a./AC	(Ui)	(V)	1000
	c.c./DC	(Ui)	(V)	1500
Impulse withstand voltage		(U imp)	(kV)	8
Rated thermal current		(Ith)	(A)	63
Rated operational current (le)	AC-21A/B	400V	(A)	63
		690V	(A)	63
		AC-22A/B	400V	(A)	63
	500V		(A)	63
	690V		(A)	63
	AC-23A/B	400V	(A)	63
		500V	(A)	45
		690V	(A)	35
	DC-21A/B(1)	220V	(A)	63
		420V	(A)	-
		560V	(A)	-
	DC-22A/B(1)	220V	(A)	63
		420V	(A)	-
		560V	(A)	-
	DC-23A/B(1)	220V	(A)	35
		420V	(A)	-
		560V	(A)	-
	Rated making capacity at 400V AC23			(A)	630
Rated breaking capacity at 400V AC23			(A)	504
Short-circuit withstand current 1 sec.			(kA)	5
Short-circuit withstand current 0,25 sec			(kA)	10
Short-circuit making capacity		(400V)	(kA)	7,5
Rated operational power AC-23A		(400V)	(Kw)	33
Rated fuse short-circuit
Back up fuse			(A)	63
R.M.S. value			(kA)	100
Peak value			(kA)	10
Mechanical endurance			n°	12000
Electrical endurance			n°	3000
Rated capacitor power at 400V			kVAR	30
Power losses for pole			(W)	0,4
Cable section			mmq	50
Bars dimension			mm	16x3

---

---

---
