Supply Voltage
|
|
|
|
|
240 VAC
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Supply Variation
|
|
- 20% to +10%
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Frequency
|
|
50 Hz
|
|
|
|
|
|
|
|
|
Power Consumption (Max.)
|
|
8 VA
|
|
|
|
|
|
|
|
|
Timing Ranges
|
|
3s to 120s
|
|
|
|
|
|
|
|
|
Pause Time
|
|
60 ms
|
|
|
|
|
|
|
|
|
Reset Time
|
|
150 ms (Max.)
|
|
|
|
|
|
|
|
|
Setting Accuracy
|
|
± 5% of Full scale
|
|
|
Repeat Accuracy
|
± 1%
|
|
|
|
|
|
|
|
|
|
|
|
|
Relay Output
|
|
Star - 1 'NO', Delta - 1 'NO'
|
|
|
Output
|
Contact Rating
|
5A @ 240 VAC / 3A @ 30 VDC (Resistive)
|
|
|
Electrical Life
|
1X105
|
|
|
|
|
|
|
|
|
|
Mechanical Life
|
5X106
|
|
|
|
|
|
|
|
|
Utilization Category
|
AC-15
|
Rated Voltage (Ue): 120/240 V, Rated Current (Ie): 3.0/1.5 A
|
|
|
DC-13
|
Rated Voltage (Ue): 24/125/250 V, Rated Current (Ie): 2.0/0.22/0.1 A
|
|
|
|
|
|
|
|
|
Operating Temperature
|
-10°C to +55°C
|
|
|
|
|
|
|
|
|
Storage Temperature
|
-20°C to +70°C
|
|
|
|
|
|
|
|
|
Humidity (Non Condensing)
|
95% (Rh)
|
|
|
|
|
|
|
|
|
LED Indication
|
Red LED 1
|
|
|
|
Enclosure
|
Flame Retardant UL94-V0
|
|
|
Dimension (W x H x D) (in mm)
|
17.5 X 90 X 58.5
|
|
|
Weight (unpacked)
|
|
60 g
|
|
|
|
|
|
|
|
|
Mounting
|
Base / DIN Rail
|
|
|
|
|
|
|
|
|
Certification
|
|
|
|
|
|
|
|
|
|
RoHS Compliant
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Degree of Protection
|
IP 20 for Terminals, IP 40 for Enclosure
|
|
