TECHNICAL DATA
Standards	Standard IEC/EN 61812 VDE 0435
Lifespan, mechanical [Operations]	10 x 106
Climatic proofing	Damp heat, constant, to IEC 60068-2-78 Damp heat, cyclic, to IEC 60068-2-30
Lifespan, mechanical DC operated [Operations]	30 x 106
Ambient temperature Ambient temperature, storage	- 45 - + 85 °C
Ambient temperature Open	-25 - +60 °C
Ambient temperature Enclosed	- 25 - + 45 °C
Mounting position	As requiredC
Mechanical shock resistance (IEC/EN 60068-2-27) Half-sinusoidal shock, 20 ms Make contact	4 g
Degree of protection Terminals	IP20
Weight	0.1 kg
Terminal capacities Solid	1 x (0.5 - 2.5) 2 x (0.5 - 1.5) mm
Terminal capacities Flexible with ferrule	1 x (0.5 - 2.5) 2 x (0.5 - 1.5) mm2
Terminal capacities Solid or stranded	1 x (20 - 14) AWG

---

---

---
