TECHNICAL DATA
Standards	EN 61000-6-1/-2/-3/-4, IEC 60068-2-6, IEC 60068-2-27
Dimensions (W x H x D)	86.5 x 86.5 x 21.5 (with actuators) 86.5 x 86.5 x 20 (without actuators) mm
Weight	0.13 kg
Mounting	2 x 22.5 mm, display fixed with 2 fixing rings. Wall thickness: without top-hat rail (CPU) 1 - 6 mm with top-hat rail 1 - 4 mm
Power loss [P]	0 W
Operating ambient temperature	-25 to 55, cold as per IEC 60068-2-1, heat as per IEC 60068-2-2 °C
Condensation	Take appropriate measures to prevent condensation
LCD display (clearly legible)	-5 - 50 - (-10 to 0 when background lighting is switched on (continuous operation)) °C
Storage	- 40 - 70 °C
Relative humidity, non-condensing (IEC/EN 60068-2-30)	5 - 95 %
Air pressure (operation)	795 - 1080 hPa

---

---

---
